Bovine, Canine, Equine, Feline, Goat, Camel, Ovine, and Swine.
*With high-quality image resolution & powerful veterinary software package.
*B mode ultrasound and backfat measuring function two-in-one, which can meet veterinarians’ most
daily demands.
*A mode ultrasound gets accurate backfat and lean rate measurement.
*TV/VGA/Freeze, three-in-one, easy to operate.
*10 kinds grid for quick measurement, make the diagnosis more efficient.
*6 kinds of operation backgrounds for different visual habits.
*Wifi connection with Phone/Pad and PC ultrasound working station to get image & data transfer &
management easily.
*OB record： detailed record the diagnosis results.
*Diagnosis List: record diagnosis quantity, easy for batch management.
*Waterproof.
a) Scanning mode：electronic convex & linear
b) Mode：B、B/B、B/M、M、A
c) Main frequency：5/6.5/7.5MHz
d) Measurement：distance, area, OB, backfat, lean rate, etc
e) Battery driving time：about 4 hours
f) Dimension：269×40×266 (mm，L×W×H)
g) N.W：2kg
h) Wifi type：11g/20MHz/2.4G
i) APP support： Android、Windows
j) Vector：PAD/Phone/PC
Main unit 1PC
6.5MHz linear rectal probe 1PC
Power supply adapter 1PC
Li-battery 1PC
Drive-by-wire switch 1PC
Metal case 1PC
