Description
Main Component |
Technical Specs |
|
| X-ray generator (including console) | Output Power | 65KW |
| Power Voltage | 380V±38V | |
| kV Range | 40~150kV | |
| mA Range | 10~800mA | |
| mAs Range | 0.1 ~630mAs | |
| Loading time | 2~10000mS | |
| X-ray tube | Small focus | 0.6 |
| Large focus | 1.2 | |
| Anode speed | 9700r/min | |
| Collimator | Inherent filtration | 1.0mm Al /75kV |
| Light Source | LED | |
| Radiographic Table | Top Table Size | 2000mmX810mmX510mm |
| Load-bearing | Less than 200kg | |
| Movement | wheels | |
| DR Machine Frame | Moving Range | 480mm ~ 1600mm |
| Rotating Range | 0°～±90°～±180° | |
| SID | 1000mm ~ 1800mm | |
| Wire Flat Panel Detector | Size | 17X17inch |
| Scintillator | CSI | |
| Pixels | 3328*3328 | |
| Resolution | 3.9 | |
| AD Conversion | 16 | |
| Computer& LCD | CPU | ≥2.8GHz |
| Memory | ≥4GB | |
| Disk Capacity | ≥1T | |
| Medical LCD | 23inch | |
